Clean rooms are a necessity in sophisticated medical processes which require a low level of pollutants and a controlled environment. Micro Puftech understands the importance of quality maintenance and hence employs the best manufacturing processes to bring to you a highly credible range of Clean Room Panels that stand proudly on industry standards.
We are the leading Clean room manufacturers in Gujarat providing clean room panels with aesthetic design that can withstand innumerable washes, cleaning, and sanitization by chemicals. The amazing durability of our Clean Rooms makes it the first choice of leading microelectronic and nanotechnology businesses.
Features
Amazing resistance to microbial and fungal development.
Minimal corner dust accumulation due to aluminum fitting coving.
Complaint with Classes 10 to 1,00,000 (ISO 4 to ISO 8) standards
Subcomponents of clean room: Clean room windows, Coving, 3D Corner Pieces and 2D Corner Pieces.
Best protection in the industry including PUF and Paper Honeycomb.
With 6 mm hardened glass on all sides and stainless steel coating, Clean room panels manufactured by Micro Puftech carry unmatched strength and durability. Our technical know-how and industry experience enables us to produce the best quality at cost-effective prices and gives us the pride of being the most trusted Clean room manufacturers in Gujarat.
Technical Details
Standard Width
1000mm, 1200mm
Insulation Thickness
50, 80
Thickness
50, 80 mm
Sheet Thickness
0.35 mm,0.4 mm,0.5 mm, 06mm
Thermal Conductivity
≤0,023 W/m.K
Sound Insulation
21.5 db
Core Material Density
38 - 42 kg/m3 (Standard)
Cladding Material
GI (Power coated ), Stainless Steel
Class
100 to 100000 Compatible
Various Protection
PUF, Paper Honey Comb
Panels Attachment
Aluminium or G.I connect with each other shape
Glass
6 mm harden glasses on all sides
Door
Single and Double Steel lock establish constructions
Coving
aluminium separate fitting coving to avoid corner dust accumulations
